B Series Dell Emc Connectrix DS-7730B DS-7720B

Brand Name DELL EMC
Model Number DS7720
Minimum Order Quantity 1
Price 10000-12000

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
High Light

connectrix ds 7720b


dell connectrix ds 7720b


dell ds 7720b

Leave a Message
Product Description

NR74Y DELL EMC DS-7720B BROCADE BR-G720 32GB FC Switch with 24 Active Ports


System Architecture Technical Specification
Fibre Channel ports DS-7730B: Switch mode (default): Minimum of 48 ports and maximum of 128 ports. Ports are enabled in
increments of 24 ports up to 128 ports via Ports on Demand (PoD) licenses; E_Ports, F_Ports, D_Ports,
Switch mode (default): Minimum of 24 ports and maximum of 64 ports. Ports are enabled in increments of 8
ports up to 56 ports using SFP+ PODs, and up to 64 ports using and a combination of SFP+ and SFP-DD
PODs; E_Ports, F_Ports, D_Ports, EX_Ports. Access Gateway default port mapping: 56 F_Ports, 8 N_Ports
DS-7720B: 64 ports (48 64G SFP+ ports, plus 8 2x64G SFP-DD ports), each supporting E_Ports, F_Ports,
M_Ports, D_Ports, and EX_Ports.
24-port base configuration; additional ports are enabled with three 8-port SFP+ PODs (Ports on Demand),
plus a 16-port SFP-DD POD (8 2x64G SFP-DD transceivers), scaling the switch from 24 ports to 64 ports.
Access Gateway default port mapping: 48 F_Ports, 8 N_Ports
Scalability Full-fabric architecture with a maximum of 239 switches
Certified maximum 4K active nodes; 56 switches, 19 hops in Fabric OS (FOS) fabrics
Performance Fibre Channel: 8.5Gb/s line speed, full duplex; 10.53Gb/s line speed, full duplex; 14.025Gb/s line speed, full
duplex; 28.05Gb/s line speed, full duplex; 57.8Gb/s line speed, full duplex; auto-sensing of 8, 10, 16, 32, and
64G port speeds. 10G optionally programmable to fixed-port speed.
